CONTI Laserline CCX

CONTI Laserline CCX is a printing plate developed for the direct printing of corrugated cardboard with integrated compressible layer. For all common types of corrugated cardboards.

Description

CONTI Laserline CCX

CONTI Laserline CCX is a printing plate developed for the direct printing of corrugated cardboard with integrated compressible layer. For all common types of corrugated cardboards.



Benefits

  • Roll material
  • “Peel off” print layer
  • Overall dimensional stability
  • Integrated compressible Layer*
  • High-resolution engraving
  • Consistent print
  • Optimized for water-based inks
  • Long lifetime / less abrasion
  • Improved ink laydown

* starting at 2.84 mm material thickness

Conti Laserline CCX

Technical Data
Printing surface Colour: SBR / grey Surface: ground Roughness RZ (DIN 4768): 12.0 μm Roughness RA (DIN 4768): 1.9 μm Surface hardness (DIN 53505): 40° Shore A
Compressibility With 135 N/cm2 ≥ 0.9 mm
Carrier Calibrated foil
Nominal thickness (ISO 12636) 2.84 to 4.2 mm ± 0.02 mm
